Tubeless Design |
Tubeless design for improving the sedimentation problem for the Disperse
solutions.
|
High Speed Dispensing
Maximum up to 3 scales and 3 recipes dispensing at the same time.
|
|
Funnel Free |
All solutions outlet are locating in one
cycle, it is suitable dispensing solution direct into dye pot
without funnel. (Patened design)
|
High Precision Serve Motor |
Using high precision Serve
Motor. It is suitable during turning
for high speed movement to the correct positions.
|
Intelligent Agitation Control |
Design to operate in both manual and computer controls. User can
activate and stop the
agitation from the computer. The software can wake up the agitation
before dispensing.
|
PLC System |
Using designed industrial PLC, high stability.
|
Fixed Coil Driving Module |
Using a Fixed coil driving module which has high stability. It
eliminates sensor error which
causes
defects of the dispenser.
|
Color Shade System |
Exclusively equipped with the Color Shade Software. Easy to store and
retrieve a dyeing
recipe
from the computer, instead of conventional color shade card.
|
Localize Language and Voice |
System can display and voice in local language, ex. Chinese, Thai,
English, & etc.
|
Link to Computer Color Matching System |
System can be linked to other computer color matching system.
|
The machine has passed TUV tested and
certificated. |
Specification]
|
Model
|
MDS115iU |
MDS79iU |
MDS43iU |
|
Dyestuff
|
108 |
72 |
36 |
|
Chemical
|
6 |
|
Water tube
|
2 |
| AUX. Auto
refill |
V |
|
Max. one batch |
22 |
14 |
12 |
|
Power
|
AC
220V,single phase |
|
Dimension |
W3300*D1130*H1250 |
W2400*D1130*H1250 |
W1500*D1130*H1250 |
|
Software |
Windows 98
/ XP/VISTA |
|
